IACS Approved Marine Studless Open Link AM1, AM2, AM3 Stainless Steel Anchor Chain

IACS Disetujui Marinir Studless Open Link AM1, AM2, AM3 Rantai Anchor Baja Rostless

Produk - Anchor dan Rantai Laut - Rantai Anchor Laut
  • Material
    AM1:Q235 AM2:CM490 AM3:CM690
  • Surface treatment
    primary color, black paint
  • Place of Origin
    CHINA
  • Nama merek
    GH
  • Sertifikasi
    CCS, BV, ABS, DNV-GL, RMRS, LR, RINA
  • Model Number
    Anchor Chain
  • Minimum Order Quantity
    1 Knots
  • Harga
    Negotiable
  • Packaging Details
    Naked
  • Delivery Time
    5-30 Days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    6000 Knots Per Month

IACS Disetujui Marinir Studless Open Link AM1, AM2, AM3 Rantai Anchor Baja Rostless

  • IACS Approved Marine Studless Open Link AM1, AM2, AM3 Stainless Steel Anchor Chain
  • IACS Approved Marine Studless Open Link AM1, AM2, AM3 Stainless Steel Anchor Chain
Dapatkan Harga Hubungi sekarang

Rantai jangkar tautan terbuka tanpa stud disetujui oleh CCS, BV, ABS, DNV-GL, LR, NK, KR, RMRS, IRS dll.

Hal ini dapat cat hitam dan galvanis sesuai dengan kebutuhan klien.

Diameter rantai/mm Ukuran tautan/mm BM1 BM2 BM3 Diameter rantai/mm Ukuran tautan/mm BM1 BM2 BM3
DF Panjang luar L × lebar luar B Beban pemutus/KN Beban pemutus/KN Beban pemutus/KN Panjang luar L × lebar luar W Beban pemutus/KN Beban pemutus/KN Beban pemutus/KN
12.5 75×45 57.81 82.6 112.8 42 252 kali 151.2 652.68 915.3 1273.6
14 84x50.4 69.93 101.9 141.51 44 264 kali 158.4 716.32 999.6 1398
16 96 x 57.4 94.72 132.3 184.83 46 276 kali 165.6 782.92 1097.6 1527.8
17.5 105×63 113.31 157.78 221.1 48 288 x 172.8 852.48 1195.6 1663.5
19 114 x 68.4 133.57 187.2 260.64 50 300×180 926.09 1293.6 1805
20.5 123 x 73.8 155.49 217.27 303.42 52 312 x 187.2 1000.48 1395.26 1952.28
22 132 x 79.2 179.08 250.9 349.4 54 324 x 194.4 1078.92 1504.66 2105.36
24 144 x 86.4 213.25 298.9 415.8 56 336 x 201.6 1160.32 1618.18 2264.2
26 156 x 93.6 250.12 350.8 488 58 348 kali 208.8 1244.68 1735.82 2428.8
28 168 kali 100.8 290.08 406.7 566 60 360×216 1332 1857.6 2599.2
30 180×108 333 467.5 649.8 62 372 kali 223.2 1422.28 1983.5 2775.36
32 192 kali 115.2 378.88 531.2 739.3 64 384 x 230.4 1515.52 2113.54 2957.32
34 204 x 122.4 427.72 599.8 834.6 66 396 x 237.6 1611.72 2247.7 3145.04
36 216 x 129.6 479.52 672.3 935.7 68 408 x 244.8 1710.88 2385.98 3338.52
38 228 x 136.8 534.28 748.7 1042.5 70 420×252 1813 2528.4 3537.8
40 240×144 592 829.1 1155.2

IACS Disetujui Marinir Studless Open Link AM1, AM2, AM3 Rantai Anchor Baja Rostless 0IACS Disetujui Marinir Studless Open Link AM1, AM2, AM3 Rantai Anchor Baja Rostless 1IACS Disetujui Marinir Studless Open Link AM1, AM2, AM3 Rantai Anchor Baja Rostless 2
